Exploring Current Collectors in PEM Fuel Cells: Types and Comparative Analysis

Introduction:

Within the intricate landscape of Proton Exchange Membrane (PEM) fuel cells, the current collector emerges as a pivotal player, orchestrating the collection of electrical current, reactant distribution, and byproduct removal. This article delves into the dual protagonists of this narrative - Bipolar Plates and Gas Diffusion Layers (GDLs), unraveling their distinctive features and presenting a comprehensive analysis of both quantitative and qualitative differences.

Bipolar Plates:

Crafted from graphite, metal, or carbon composites, bipolar plates embody versatility as both current collectors and reactant distributors. Positioned strategically between individual cells in a stack, these plates not only ensure effective electrical connectivity but also contribute structurally to the fuel cell stack. Bipolar plates boast a lightweight nature, excellent electrical conductivity, and play a pivotal role in overall fuel cell efficiency.

Gas Diffusion Layers (GDLs):

Composed of porous materials like carbon paper or carbon cloth coated with conductive layers, GDLs act as conduits for reactant gases and electron collectors during electrochemical reactions. Their high porosity facilitates efficient gas diffusion, while satisfactory electrical conductivity supports the crucial task of electron transfer. While slightly less conductive than bipolar plates, GDLs contribute to the reduction of the fuel cell stack's overall weight.

Quantitative Differences:

1. Conductivity: Bipolar Plates: High electrical conductivity ensures efficient electron transport. GDLs: Slightly less conductive but sufficient for electron transfer.

2. Weight:Bipolar Plates: Heavier due to the materials used. GDLs: Lighter, contributing to an overall reduction in stack weight.

3. Cost: Bipolar Plates: Generally, more expensive, especially with high-performance materials. GDLs: Generally, more cost-effective, particularly with materials like carbon paper.

4. Complexity: Bipolar Plates: Intricate design may involve additional manufacturing steps. GDLs: Simpler to manufacture and integrate into the fuel cell stack.

Qualitative Differences:

1. Efficiency: Bipolar Plates: Tend to contribute to higher overall fuel cell efficiency. GDLs: While efficient, may exhibit slightly lower efficiency compared to bipolar plates.

2. Durability: Bipolar Plates: Generally known for robustness and longevity. GDLs: May be prone to wear over time, impacting long-term durability.

3. Corrosion Resistance: Bipolar Plates: Often possess better corrosion resistance, ensuring prolonged performance. GDLs: May require additional protective measures to mitigate corrosion effects.

4. Manufacturability: Bipolar Plates: More complex designs may pose challenges in the manufacturing process. GDLs: Simplicity in design contributes to ease of manufacturing and integration.
