Plug-and-play PEM electrolyzer system. 0–160 mL/min at >99.9% purity. Single phase AC, regulated 0.2–4 bar outlet.
Lead time: 4–6 weeks
What is a PEM Electrolyzer System?
A PEM electrolyzer system is a complete, self-contained hydrogen generation unit built around a PEM electrolyzer stack. Unlike bare electrolyzer cells that require an external DC power supply and system integration, a PEM electrolyzer system includes everything needed to produce hydrogen from a standard AC mains connection — integrated rectifier and power supply, stack assembly, gas-liquid separator, pressure regulation, safety shutoff, and a controlled hydrogen outlet.
HPES systems operate on single phase AC mains (230V, 50Hz) and deliver hydrogen at a defined outlet pressure — either regulated low pressure (0.2–4 bar) for direct instrument or test bench supply, or at 16 bar for applications requiring higher delivery pressure. Industrial HPES systems (1–10 Nm³/hr) deliver hydrogen at 35 bar with full balance-of-plant integration.
The HPES range covers flow rates from 160 mL/min to 10 Nm³/hr — making it suitable for analytical instrument supply, fuel cell test benches, hydrogen safety research, pilot-scale hydrogen generation and industrial hydrogen supply applications. All HPES systems produce hydrogen at >99.9% purity directly at the outlet under normal operating conditions.
